Features and Specifications:

Light Source ：PHILIPS MSD Silver 420W/ LL

Diameter of Frontal Lens: 180 mm

Angle :  1.7°

Color Temperature Output of Fixture: 6500K

Pan & Tilt: Pan Movement: 540°, Tilt Movement: 270°, Automatic Pan/Tilt position correction

Linear CMY color mixing& Linear CMY color mixing Linear CTO Color Correction

1 Color Wheel: 6 colors

2 Color Wheel: 6 colors

Gobo Wheel: 1 Static Gobo Wheel  17gobos, plus open

Prism/ Frost Filter

Outstanding strobe effect with variable speed

Smooth dimming 0-100%

Motorized zoom and focus

1Diffuser

Protocols: DMX512,RDM

Control Channels:：21

Input Voltage Range: 100-240Vac; 50/60Hz

Power Consumption:615W

Power In/Out: Waterproof power connector in/out

Data In/Out: 3-pin waterproof XLR

Fixture Dimensions：:705*375*300mm

Weight:30kg

Carton Dimensions: 750*440*460mm
